| Max Dia. of Workpiece | 3 inches |
|---|---|
| CNC Control | no |
| Dimensions | 62" X 84" X 75" |
| Weight | 7600 pounds |
| Tesker Model 35 2-Die Machine Specifications: | |
| Type | Infeed |
| Capacity | 3" |
| Rolling Pressure | Adjustable to 40,000 lbs. |
| Motors | |
|---|---|
| Spindle Drive | 30 HP |
| Coolant | 1/4 HP, Capacity 80 Gal |
| Dies | |
| Maximum Diameter | 7-1/2" |
| Maximum Face Width | 6" |
| Spindle Size | 2-1/2" (other sizes available) |
| Spindle Speeds | Variable |
| Spindle RPM | 30-150 (other speeds available) |
| Floor Dimensions | |
| Width | 62" |
| Length | 84" |
| Height | 75" |
| Weight | 7,600 lbs. |
