| achining Stroke ( X x Y x Z ) | 15.7" x 11.8" x 11.8" |
| Machining Movement (C) | 360 Degrees |
| Chuck to Table Clearence | 6.0" x 17.8" |
| Worktank Size | 37" x 24" x 14" |
| Table Size | 28" x 20" |
| Tank Type | 3-Sided Drop Tank |
| Maximum Workpiece Dimensions | 33.5" x 25.2" x 9.8" |
| Maximum Workpiece Weight | 1,540 lbs |
| Maximum Current | 80 Amps |
| Maximum Electrode Weight | 110 lbs/22 lbs with C-Axis |
| Dielectric Capacity | 106 Gal |
| Machine Shipping Dimensions | 84" x 56" x 94"H |
| Machine Base Only Weight | 7,480 lbs |
| Power Supply Shipping Dimensions | 22" x 46" x 74"H |
| Machine Total Weight | 9,365 lbs |
