Used 2008 MAZAK VARIAXIS J-600/5X | Machining Centers, Vertical, (5-Axis or More)

Table Size 23.6" x 19.6" (Trunnion)
Max. Table Load 11,000 Lbs.
X Travel 33.46"
Y Travel 21.65"
Z Travel 20.08"
Spindle Speed 12000 RPM
Tool Capacity (ATC) 30
Main Spindle Motor 15 hp
Spindle Taper CAT 40
5 Axis Programmable Axis's
Full 5 Axis's Contouring
Table Type A-Axis Trunnion Tilt Range 210 DEGREES
Table Type C-Axis Table Rotation .001 N/C Contouring 360,000 Degrees
Coolant Thru High Pressure
Coolant System 213 psi
Tool Probe/Auto Tool Length Measurement
Control CNC (Mazatrol Matrix 2)

SPECIFICATIONS:
MAXIMUM WORKPIECE DIAMETER 28.740"
MAXIMUM WORKPIECE HEIGHT 17.720"
SPINDLE TAPER CAT 40
MAXIMUM SPEED 12000 RPM
MOTOR OUTPUT (30 MINUTE RATING) 15.0 HP / 11 KW
MAGAZINE NUMBER OF TOOLS 30
ROTARY AXIS SPINDLE TILT/B AXIS 210 DEGREES
TABLE INDEXING (C AXIS) 360.0000 DEGREES
(X AXIS)TRAVEL 33.46"
(Y AXIS)TRAVEL 21.65"
(Z AXIS)TRAVEL 20.08"

Equipped With

EQUIPPED WITH:
MAZATROL MATRIX 2 CONTROL
30 TOOL ATC - CAT 40
HI PRESSURE COOLANT THRU SPINDLE - 213 PSI/ 15KGF
MIST COLLECTOR
ADDITIONAL WORK LIGHT
ETHERNET OPERATION FUNCTION
WORK SETTING ERROR COMPENSATION
CHIP CONVEYOR RIGHT DISPOSAL (HINGE/ FOR STEEL)
ALL AVAILABLE MANUALS
